ZHZY-3.5F
Special lifting machine for four wheel positioning
ZHZY-3.5F
|
Main technical parameters
|
|
|
Lifting capacity
|
Main engine4000kg; Auxiliary jack2500kg
|
|
lifting height
|
Main engine1750mm; Auxiliary jack390mm
|
|
lifting time
|
60S
|
|
power and motor
|
3ph:3.0kw,220v /380v,50/60hz
1ph:3.0kw,2p,220v,50/60hz
|
|
Air supply pressure
|
0.6～0.8MPA
|
|
Rated oil pressure
|
25mpa-28mpa
|
|
overall weight
|
2300kg
|
1、With electric hydraulic stations of bipolar auxiliary jack.
2、Hydraulic synchronous control, synchronization precision.
3、The hydraulic system adopts Italy electromagnetic valve and imports of seal, ensure the stability and service life of the machine:
4、This machine is composed of a machine frame、hydraulic system、
pneumatic system and electric system is composed of four parts.
5、Can be matched with various locating turntable .
